Enphase, Encharge 10.5kWh
Cat. No. ENCHARGE-10-1P-NA

The Encharge 10 all-in-one AC-coupled storage system, comprised of three base Encharge 3 storage units, provides a total usable energy capacity of 10.1kWh and twelve embedded grid-forming microinverters. Connect multiple Encharge 10 storage systems to maximize backup potential for whole home backup.

Enphase, Encharge 10.5kWh LFP Battery, with 12 integrated IQ8X-BATT inverters, NEMA 3R, ENCHARGE-10-1P-NA

Proven high reliability IQ Series Microinverters
Ten-year limited warranty
Three independent Encharge storage base units
Twelve embedded IQ 8X-BAT Microinverters
Passive cooling (no moving parts/fans)
Grid-forming capability for backup operation
  Remote software and firmware upgrade
Mobile app-based monitoring and control
Support for self consumption
Utility time of use (TOU) optimization
Fully integrated AC battery system
Quick and easy plug-and-play installation
Interconnects with standard household AC wiring
Cells safety tested
Lithium iron phosphate (LFP) chemistry for maximum
safety and longevity

Product Weight 146.760 lbs
Product Depth 48.000 inches
Product Height 47.800 inches
Product Width 48.000 inches
